Toyota 80V Electric Pneumatic Forklift

80V Electric Pneumatic Forklift

ORS (Operator Restraint System) Full-Suspension Vinyl Seat
Retractable Seat Belt
Heavy-Duty, Non-Slip Floor Mat
Memory Tilt Steering Column

Want to maintain an all-electric fleet, but need a rugged, outdoor solution? Look no further than Toyota’s 80V Electric Pneumatic Forklift. These electric powerhouses combine the power, durability, and reliability of internal combustion trucks with the ergonomics and speed of electric forklifts. With a capacity ranging from 5,000-17,500 lb., these machines are ready to tackle any challenge, whether you’re operating indoors or outdoors.

80V ELECTRIC PNEUMATIC FORKLIFT SPECIFICATIONS

MODEL NUMBER	LOAD CAPACITY* (LBS.)	MAX. TRAVEL SPEED FULL LOAD (MPH)	MAX. LIFT SPEED FULL LOAD (FPM)	MAX. GRADEABILITY FULL LOAD (%)	BASIC RIGHT ANGLE STACK** (IN.)
05-8FBM25T	5,000	11.8	91	15-24	100.7
05-8FBM40T	8,000	11	68.9	11.3-15	120.5
05-8FBM45T	9,000	11	68.9	9.5-14	121.1
05-8FMB50T	11,000	11	65	8.8-13	126.5
9FBM20T	4,000	11.8	90.5	23-29	104.1
9FBM25T	5,000	11.8	90.6	19-29	110
9FBM30T	6,000	11.8	78.7	17-29	110.8
9FBM35T	7,000	11.8	72.8	15-29	111.8
9FBM60T	13,000	11	75	7-19	146
9FBM70T	15,500	11	71	6.3-18	146
9FBM80T	17,500	11	63	5.6-16	146.5
9FBH80T	17,500	10	63	5.2-16	152
